Troubleshooting Tenant Attach and Device Action Issues

Microsoft has given us countless different products and services over the last few decades. Undoubtedly, we know the important role they have played for individuals and businesses on the journey towards utilizing technology to better our lives. When looking at the Microsoft ecosystem, one of the best examples of undeniable excellence is the Microsoft Intune family of products.

With this product, Microsoft gives you an integrated solution that enables you to seamlessly manage all your devices. Central to this solution is the single console that we know as the Microsoft Intune admin center which brings together Intune and Configuration Manager.

The capabilities of this platform can offer your organization a premium device-management solution like no other. The area that we want to focus on today will have to do with the troubleshooting of tenant attach and device actions.

Comparing Tenant Attach to Co-management

For a lot of people, it may be difficult to distinguish between these two. So, let’s start by looking at where these two options differ. Both of these make up two of the three primary cloud attach features. For a Configuration Manager environment to be cloud-attached, it has to use at least one of the three primary cloud attach features.

Tenant Attach gives you the advantage of having your device records in the cloud as well as the ability to take actions on these devices from the cloud-based console. IT admins can perform remote actions on tenant-attached devices such as sync machine policy, sync user policy, run scripts on clients, deploy applications, and much more.

Furthermore, users will be able to manage endpoint security for the attached devices from the Intune admin center for both Windows Servers and Client devices.

On the other hand, Co-management is going to modify your on-premises Configuration Manager environment without the need for a significant migration effort.

One of the more attractive features of Co-management is how it allows you to easily switch workloads such as compliance policies from SCCM to Intune. By enabling you to manage workloads from the cloud, your organization gets to benefit from a simpler device management experience.

Tenant Attach prerequisites

To make use of Tenant Attach, you will need to meet the following requirements:

  • When you decide to apply this onboarding change, you’ll need to sign in using an account that is a Global Administrator.
  • An Azure cloud environment.
  • With version 2107, United States Government customers will be able to use tenant attach features in the US Government cloud such as account onboarding, tenant sync to Intune, device sync to Intune, and device actions in the Microsoft Intune admin center.
  • The Azure tenant and the service connection point must have the same geographic location.
  • To access the Microsoft Intune admin center, there needs to be at least one Intune license for the administrator.
  • The administration service in Configuration Manager needs to be functional.
  • If your central administration site has a remote provider, you need to follow the instructions for the CAS has a remote provider scenario in the CMPivot article.

PERMISSIONS

In addition to the above, there will also be a few requirements for the user accounts performing device actions and these include:

  • The user account should be a synced user object in Microsoft Entra ID (hybrid identity).
  • The Initiate Configuration Manager action permission under Remote tasks in the Microsoft Intune admin center.

The troubleshooting process

Now and again, all of us will encounter issues with the products and services we use. That’s why it’s important to work with providers that offer great support services so that we avoid downtime. Microsoft puts a lot of effort into ensuring that customers get as much support as they need for the various products in its ecosystem. Understandably, tenant attach is no different.

At this point, most admins should be aware that you can sync Configuration Manager clients to the Microsoft Intune admin center. And from that admin center, some client actions can run on the synchronized clients.

These available actions include the sync user policy, sync machine policy, and app evaluation cycle. After an administrator runs an action from the Microsoft Intune admin center, the notification request will forward to the Configuration Manager site. And from there, it will forward to the client.

LOG FILES

The logs you need to use will be found on the service connection point and these are:

  • CMGatewaySyncUploadWorker.log
  • CMGatewayNotificationWorker.log

You should also use the logs located on the management point:

  • BgbServer.log

Lastly, there are other logs that will be found on the client:

  • CcmNotificationAgent.log

Review your upload

You’ll need to follow the steps given below:

  • Open CMGatewaySyncUploadWorker.log from <ConfigMgr install directory>\Logs.
  • You will see the next sync time recorded in a log entry similar to this format Next run time will be at approximately: 02/28/2024 10:15:30.
  • The log entries that you should look at for device uploads should be something like this Batching N Records. In this instance, N represents the number of changed devices uploaded since the last upload.
  • Admins should expect uploads every 15 minutes for changes. However, once that is done, they will probably need to wait up to 10 minutes to view the client changes appearing in the Microsoft Intune admin center.

Configuration Manager components and log flow

SMS_SERVICE_CONNECTOR: Will utilize the Gateway Notification Worker to process the notification from the Microsoft Intune admin center.

SMS_NOTIFICATION_SERVER: Receives the notification and subsequently creates a client notification.

BgbAgent: The client gets the task and runs the requested action.

SMS SERVICE CONNECTOR

Following the initiation of an action from the Microsoft Intune admin center, the CMGatewayNotificationWorker.log will process the request.

Received new notification. Validating basic notification details…

Validating device action message content…

Authorized to perform client action. TemplateID: RequestMachinePolicy TenantId: a1b2c3a1-b2c3-d4a1-b2c3-d4a1b2c3a1b2 AADUserID:     a1b2c3a1-b2c3-d4a1-b2c3-d4a1b2c3a1b2

Forwarded BGB remote task. TemplateID: 1 TaskGuid: a43dd1b3-a006-4604-b012-5529380b3b6f TaskParam: TargetDeviceIDs: 1

A notification is received from the Microsoft Intune admin center.

Received new notification. Validating basic notification details..

Validation of user and device actions is carried out.

Validating device action message content…

Authorized to perform client action. TemplateID: RequestMachinePolicy TenantId: a1b2c3a1-b2c3-d4a1-b2c3-d4a1b2c3a1b2 AADUserID:     a1b2c3a1-b2c3-d4a1-b2c3-d4a1b2c3a1b2

Forwarding of the remote task to the SMS NOTIFICATION SERVER.

Forwarded BGB remote task. TemplateID: 1 TaskGuid: a43dd1b3-a006-4604-b012-5529380b3b6f TaskParam: TargetDeviceIDs: 1

SMS NOTIFICATION SERVER

At this point, you should be expecting a task to be sent from the management point to the corresponding client as soon as the message has been forwarded to the SMS NOTIFICATION SERVER. In the BgbServer.log, which is on the management point, you should see the following:

Get one push message from database.

Starting to send push task (PushID: 7 TaskID: 8 TaskGUID: A43DD1B3-A006-4604-B012-5529380B3B6F TaskType: 1 TaskParam: ) to 1 clients  with throttling (strategy: 1 param: 42)

BgbAgent

The last step will occur on the client and you can view it in the CcmNotificationAgent.log. As soon as the task has been received, it will then request the scheduler to carry out the action. And once the action has been carried out, a confirmation message will appear:

Receive task from server with pushid=7, taskid=8, taskguid=A43DD1B3-A006-4604-B012-5529380B3B6F, tasktype=1 and taskParam=

Send Task response message <BgbResponseMessage TimeStamp=”2020-01-21T15:43:43Z”><PushID>8</PushID><TaskID>9</TaskID><ReturnCode>1</ReturnCode></BgbResponseMessage> successfully.

Common issues

In this section, we’ll take a look at some of the issues that admins may often encounter.

Unauthorized to perform client action

For whatever reason, there may be situations where administrators may not have the required permissions in Configuration Manager. If that happens, you’ll see an Unauthorized response in the CMGatewayNotificationWorker.log.

Received new notification. Validating basic notification details..

Validating device action message content…

Unauthorized to perform client action. TemplateID: RequestMachinePolicy TenantId: a1b2c3a1-b2c3-d4a1-b2c3-d4a1b2c3a1b2 AADUserID: 3a1e89e6-e190-4615-9d38-a208b0eb1c78

Administrators should verify that the user running the action from the Microsoft Intune admin center has all the necessary permissions on the Configuration Manager site.

Known issues

Data synchronization failures

When there are issues with the hierarchy onboarding configuration, you may end up facing challenges with viewing the tenant attach details in the Microsoft Intune admin center. This could potentially happen in situations where onboarding a hierarchy that has already been onboarded occurs. However, you may also detect this issue from entries in the GenericUploadWorker.log and CMGatewayNotificationWorker.log files.

Workaround for data synchronization failures

Resetting the tenant attach configuration will require you to follow the steps below:

  • Offboard the hierarchy. If the tenant attach is already enabled, you need to disable device upload and offboard by editing the co-management properties.
  • In the Configuration Manager admin console, go to Administration > Overview > Cloud Services > Cloud Attach. (Select the Co-management node if it is version 2103 and earlier)
  • In the ribbon, select Properties for your co-management production policy.
  • Next, you need to remove the Upload to Microsoft Endpoint Manager admin center selection from the Configure upload tab.
  • Once everything’s completed, select Apply.

You need to give the service about 2 hours to clean up the existing record. Once the above has been completed, you can onboard the hierarchy again.

Example errors in log files that require resetting the tenant attach configuration

Errors for AccountOnboardingInfo and DevicePost requests in GenericUploadWorker.log

[GetNotifications] Response from https://us.gateway.configmgr.manage.microsoft.com/api/gateway/Notification is: 401 (Unauthorized)

Response status code: 401 (Unauthorized) Activity ID: 4c536a72-fd7f-4d08-948a-3e65d2129e44

Web exception when getting new notification

Exception details:

[Warning][CMGatewayNotificationWorker][0][System.Net.WebException][0x80131509]

The remote server returned an error: (401) Unauthorized.    at Microsoft.ConfigurationManager.ServiceConnector.ExtensionMethods.<GetResponseAsync>d__13.MoveNext()

Response in the web exception: {“Message”:”An error has occurred.”}

Errors for device actions in CMGatewayNotificationWorker.log

[GetNotifications] Response from https://us.gateway.configmgr.manage.microsoft.com/api/gateway/Notification is: 401 (Unauthorized)

Response status code: 401 (Unauthorized) Activity ID: 4c536a72-fd7f-4d08-948a-3e65d2129e44

Web exception when getting new notification

Exception details:

[Warning][CMGatewayNotificationWorker][0][System.Net.WebException][0x80131509]

The remote server returned an error: (401) Unauthorized.    at Microsoft.ConfigurationManager.ServiceConnector.ExtensionMethods.<GetResponseAsync>d__13.MoveNext()

Response in the web exception: {“Message”:”An error has occurred.”}

Specific devices don’t synchronize

Another issue that you may need to deal with has to do with specific devices, which also happen to be Configuration Manager clients, not being uploaded to the service. So, what devices should you expect to be potentially affected by this issue?

In scenarios where a device is a distribution point that uses the same PKI certificate for both the distribution point functionality and its client agent, then the device won’t be included in the tenant attach device sync.

Furthermore, administrators should look out for the behavior that is typical in such instances. During the on-boarding phase as you are going through the tenant attach process, a full sync will be carried out the first time.

You should be aware that any other sync cycles after this one will be delta synchronizations. If the impacted devices are updated in any way, that update will result in the device being removed from the sync.

When the Configuration Manager site is configured to require multi-factor authentication, most tenant attach features don’t work

More troubleshooting

If you find yourself in a situation where the SMS provider machine that communicates with the service connection point is configured to use multi-factor authentication, you won’t be able to install applications, run CMPivot queries, and perform other actions from the admin console.

Instead, you will get a 403 error code, forbidden. What you would normally do to address this is to configure the on-premises hierarchy to the default authentication level of Windows authentication.

The platform is designed to enable you to determine what the minimum authentication level should be for admins to access Configuration Manager sites. You should view this as a great feature for enhancing security because it means that admins have to sign in to Windows with the appropriate level before they can access Configuration Manager.

Authentication

Furthermore, this applies to all components that access the SMS provider. Configuration Manager supports a handful of authentication levels and these are as follows:

  • Windows authentication: Authentication with Active Directory domain credentials is necessary. Note that this setting represents the previous behavior, as well as the current default setting.
  • Certificate authentication. Authentication with a valid certificate that has been issued by a trusted PKI certificate authority is necessary. You also need to know that you don’t configure this certificate in Configuration Manager. Configuration Manager requires the admin to be signed into Windows using PKI.
  • Windows Hello for Business authentication: In this case, you need a strong two-factor authentication that’s linked to a device and also uses a PIN or biometrics. Before choosing this particular setting, you need to note that the SMS Provider and administration service will require the user’s authentication token to contain a multi-factor authentication (MFA) claim from Windows Hello for Business. In simple terms, all this means is that users of the console, SDK, PowerShell, or administration service are required to authenticate to Windows with their Windows Hello for Business PIN or biometric. If not done this way, the site rejects the user’s action. Another key thing to also remember is that this behavior is specific to Windows Hello for Business and does not apply to Windows Hello.

What to do when Configuration Manager components for tenant attach fail to connect to the backend cloud service

Another issue that some have encountered concerns the failure of Configuration Manager components for tenant attach to connect to the backend cloud service when you run a client action from the Microsoft Intune admin center. In those instances, you may see the error given below:

Failed to check and load service signing certificate. System.ArgumentException: Mismatch certificate subject name

According to the information available from Microsoft, this problem occurs in versions earlier than the Configuration Manager version 2203 hotfix rollup after a change in public certificates on July 27, 2022. The reason for this has to do with the change that came about in public certificates on July 27, 2022, where OU=Microsoft Corporation was removed from the public certificate.

Even though this change was carried out, the configuration manager database still retained the old subject name and this then caused the load check failure. Below are some example entries in the CMGatewayNotificationWorker.log file in the top-level site in the hierarchy:

Error occured when process notification with notification Id <notification Id>. Ignore the notification. SMS_SERVICE_CONNECTOR_CMGatewayNotificationWorker

Exception details: SMS_SERVICE_CONNECTOR_CMGatewayNotificationWorker

[Warning][CMGatewayNotificationWorker][0][System.IO.InvalidDataException][0x80131501]

Failed to check and load service signing certificate. System.ArgumentException: Mismatch certificate subject name at Microsoft.ConfigurationManager.ManagedBase.CertificateUtility.ServiceCertificateUtility.VerifyCertificate(X509Certificate2 certificate, Boolean crlCheck, X509Chain& certificateChain, X509Certificate2Collection extraStore)

and at Microsoft.ConfigurationManager.ManagedBase.CertificateUtility.ServiceCertificateUtility.Reload()

at Microsoft.ConfigurationManager.ManagedBase.CertificateUtility.ServiceCertificateUtility.Exists(String thumbprint)

and at Microsoft.ConfigurationManager.ServiceConnector.AccountOnboardingWorker.\<RefreshServiceSigningCertificateIfNotExistsAsync>d__19.MoveNext()

ADDRESSING THE ISSUE

To address this challenge, there are a couple of methods that you can employ. The first thing you can do is to install the Configuration Manager version 2203 hotfix rollup if you happen to be running Configuration Manager version 2203.

However, if your version of Configuration Manager is a previously supported one, you’ll first need to upgrade to Configuration Manager version 2203. After doing that, you can proceed with the installation of the Configuration Manager version 2203 hotfix rollup.

In the update rollup for Microsoft Endpoint Configuration Manager current branch, version 2203, the following issues have been addressed:

  • Application approvals through email not working with a cloud management gateway due to a missing Microsoft Entra token.
  • Metadata revisions to previously published metadata-only updates not being synchronized to Windows Server Update Services (WSUS) as expected.
  • If a window happens to be left open for a few minutes, the task Sequence Editor running on Windows Server 2022 would fail to apply changes to a task sequence. After this happens, you would see the following message:

Error connecting to provider, smsprov.log may show more details.

  • In situations where the Client checking status frequency (minutes) value has been set below 60, the BitLocker compliance status will be temporarily inaccurate.
  • Admins have also experienced the incorrect removal of some users and their group memberships by the SMS_AZUREAD_DISCOVERY_AGENT thread of the SMA_Executive service in cases when the site server is configured with a non-US English locale. You’ll have have noticed the removals occurring when the discovery cycle runs after the 12th day of the month. Errors will be recorded in the SMS_AZUREAD_DISCOVERY_AGENT.log file at various times during the discovery cycle and they will be similar to the following:
  1. ERROR: Encountered SqlException The conversion of a nvarchar data type to a datetime data type resulted in an out-of-range value.

2. ERROR: Exception message: [The conversion of a nvarchar data type to a datetime data type resulted in an out-of-range value.]

3. ERROR: Group full sync request failed. Exception: System.NullReferenceException: Object reference not set to an instance of an object.

More troubleshooting

  • When adding a CMPivot query as a favorite, it is split into two lines and characters are removed.
  • When searching Software Update Groups in the Configuration Manager console, the Name criteria is not an option.
  • Instead of the value you may have previously noticed, the Browse button for Content location in the properties for a deployment would return an empty location.
  • The implicit uninstall setting won’t be respected by an application that is targeted to a device collection but deployed in the context of the user.
  • Typing a Name value in the Create Orchestration Group wizard occurs at a below normal speed.
  • A misleading error message (false negative) is generated on a target distribution point that is co-located with a site server. You could expect to see this during content distribution from a parent site to a child site. In the distmgr.log, the false negative will appear in this format:

~RDC:Failed to set access security on \\<SiteServerFQDN>\SMSSIG$\<PkgID>.1.tar for package <PkgID> signature file

Conclusion

In some cases, unfortunately, both options involving installation of the Configuration Manager version 2203 hotfix rollup may not work to fix the above issues. For those situations, you’ll need to open a support ticket with the Configuration Manager support team.

From there, you’ll be able to get the appropriate assistance to resolve the problem in the supported version of Configuration Manager in your environment.

Microsoft Intune – A Comprehensive Design Guide

So much technological innovation is going on all around us that it can at times be overwhelming to keep up with everything. And mobile device management solutions are no different. Which of the solutions do you pick to ensure that your organization is using the best management solution? Difficult to say.

In fact, plenty of organizations opt for using multiple device management solutions at the same time. Although, there may be advantages to that, finding a single comprehensive solution to provide you with everything you need in a single package offers greater convenience. This is why I’ve decided to write this guide on Microsoft Intune, a solution that can optimize your IT operations to perform at unprecedented levels.

Before you begin

In the first blog of this Microsoft Intune series, I looked at the different stages of planning that you’ll have to go through if you want to have a seamless adoption of Microsoft Intune in your organization. As one would expect, adopting any new technology will bring with it a few teething problems hence the need for a plan that covers as many potential scenarios as possible.

Getting started

Some of the key areas of consideration include:

  • Have your goals clearly itemized. This includes concerns about data security, device protection, access to organizational resources, and other objectives.
  • Creating a complete inventory of all the devices in your organization that will have access to company resources. So, this would include both organization-owned and personal devices as well as information about the platforms they are running.
  • You’ll also need to look at all potential costs and licensing. There will probably be some additional services and programs that you’ll need so all these will need consideration.
  • You probably already have existing policies and infrastructure that your organization relies on. However, all these will require reviewing when thinking of moving to Intune. This is because you may need to develop some new policies.
  • With the above in place, you need to determine a rollout plan that has pre-defined objectives and can ensure that the rollout proceeds as smoothly as possible.
  • As you introduce Intune to your organization, you cannot ignore the value of communicating with your users. People in your organization need to understand what Intune is, what value it will bring to your organization, and what they should expect.
  • Lastly, it’s crucial that you fully equip your IT support and helpdesk staff. You can do this by involving them in the adoption process from the early stages. Therefore, it enables them to learn more about Intune and gain invaluable experience. With the skills that they acquire, they’ll be able to play important roles in the full rollout of Microsoft Intune as well as help in the swift addressing of any potential issues that arise.

Design creation

After you go through your planning phase, you can start to look at creating a specific design for your organization’s Microsoft Intune setup. Coming up with a design will require you to review all the information already collected throughout the planning phase.

This is going to allow you to put together information on your existing environment. This includes the Intune deployment options, the identity requirements for external dependencies, the various device platform considerations, as well as the delivery requirements. One of the great things about Microsoft Intune is that you don’t need to worry about significant on-premises requirements to use the service.

However, having a design plan is still a good idea because it allows you to have a clear outline of the objectives that you want to achieve so that you can be certain about choosing the management solution.

Assessing your current environment

A logical place for you to begin your planning is with your current environment. Having a record of this environment can help to further clarify where you currently are and what the ultimate vision is. This record can also serve you well during the implementation and testing phases. There you can make numerous changes to the design.

Recording the environment

There are several methods for recording your existing environment such as:

  • Identity in the cloud – you can note if your environment is federated. Additionally, you can determine MFA enabling. Also, which of Azure AD Connect or DirSync do you use?
  • Email environment – you need to record what email platform you currently use. Also consider if it is on-premises or on the cloud. And if you’re using Exchange, for instance, are there any plans for migrating to the cloud?
  • Mobile device management solutions – you’ll need to go over all the mobile device management solutions (MDM) currently in use. Also consider what platforms they support. It’s also important to note down which solutions you’re using for corporate as well as BYOD use-case scenarios. Additionally, it’s useful to have a record of who in your organization is using these solutions, their groups, and even their use patterns.
  • Certificate solution – note whether or not you have implemented a certificate solution, including the certificate type.
  • Systems management – have a detailed record of how you manage your PC and server management. This, means you have to note what management platform you are using, whether it’s Microsoft Endpoint Configuration Manager or some other third-party solution.
  • VPN solution – you should note what you’re currently using as your VPN solution of choice. And if you’re using it for both personal devices and organization-issued devices.

Note to consider

In addition to having a detailed record of your current environment, it’s also important to not forget any other plans in the works. Or consider those on the docket for implementation. Especially if they could affect what you have already noted down in the record of your environment. For instance, your record could show that multi-factor authentication is off. Still, you could be planning to turn it on in the near future so you’ll want to highlight this coming change.

Intune tenant location

The location where your tenant will reside is extremely important to decide before making the decision to subscribe to Microsoft Intune. And this is especially so for organizations that operate across different continents. The reason why it’s so important to carefully think this through, is that you’ll need to choose the country/region when you are signing up for Intune for the first time. After you have made your selection, you won’t have the option to change your decision later on. The regions that are currently available for selection include North America, Europe, the Middle East, Africa, as well as Asia and Pacific.

External dependencies

When we talk about external dependencies, we are referring to products and services that are not part of the Intune package. But they may be part of the prerequisites to use Intune. In addition, they could also be elements that can integrate with Intune. Given how integral external dependencies may be to your use of Intune, you’ll need to have a comprehensive list of any and all requirements. Make sure they’re for these products and services as well as the instructions for their configuration.

Below we’ll look at some of the more common examples of external dependencies that you will encounter:

Identity

Simply put, identity gives us the element through which we can recognize all the various users that belong to your organization as well as those enrolling devices. If you want to use Intune then you’ll need to be using Azure AD as your user identity provider. This comes with several advantages. One such benefit is enabling IT admins to enhance organizational security by controlling access to apps and app resources. Therefore, it’s easier to meet your access governance requirements. App developers will also benefit from the ability to leverage Azure AD APIs for creating personalized experiences using organizational data.

For those that are already using Azure AD, you’ll get the added convenience of continuing with the current identity that you have in the cloud. Not only that, but you also get the added benefit of Azure AD Connect. This happens to be the ideal solution for synchronizing your on-prem user identities with Microsoft cloud services. For organizations that already have an Office 365 subscription, the best scenario would be to ensure that Intune also uses the same Azure AD environment.

User and device groups

These groups play an important role as they are responsible for defining who exactly the target of a deployment will be. This will also include profiles, apps, and policies. It’s therefore important to come up with the user and device groups that your organization will need. And the best way to go about this may be for you to start by creating these groups in the on-premises Active Directory. And then once you have done this you can proceed to synchronize to Azure AD.

Public key infrastructure (PKI)

The role of PKI is to provide users or devices with certificates that will enable secure authentication to various services. So, when considering adopting Microsoft Intune you should be aware that it supports a Microsoft PKI infrastructure. Mobile devices can provide device and user certificates, so you meet all certificate-based authentication requirements. However, before you proceed with the use of certificates, you’ll need to verify a few things first:

  • Check whether or not you even need the certificates.
  • Check if certificate-based authentication provides support by the network infrastructure.
  • Lastly, you need to verify whether there are any certificates already in use in the existing environment.

For some, they may need to use these certificates with VPN, Wi-Fi, or e-mail profiles with Intune. But to do that, you first need to check if you have a supported PKI infrastructure in place. It needs to be ready for the creation and deployment of certificate profiles. Furthermore, when it comes to the use of SCEP certificate profiles, you have to decide how to host the Network Device Enrollment Service feature. Not only that, but you also need to determine how to carry out any communication.

Pre-requisites for devices

As you proceed with your design plan for Microsoft Intune, you’ll also need to turn your focus over to devices and the requirements. Expectedly, as with any management solution, there will be devices to consider. But there will also be platform considerations that will determine suitability for Intune management.

Device platforms and Microsoft Intune

One of the most important parts of the design plan is to consider the device platforms that will be supported by your chosen management solution. Therefore, before making the final decision about whether or not to go with Intune, you should create a complete inventory of the devices that will be in your environment. Then crosscheck whether or not they have proper support by Intune.

Understanding systems

The table below contains the supported configurations.

Operating systemsAndroid iOS/iPadOS Linux macOS Windows
Chrome OS
Apple (For device enrollment scenarios and app configuration that you get via Managed devices app configuration policies, Intune will require iOS 14.x or later. The same requirement also applies to Intune app protection policies and app configuration.)Apple iOS 14.0 and later   Apple iPadOS 14.0 and later   macOS 11.0 and later
Android (For device enrollment scenarios and app configuration that you get via Managed devices app configuration policies, Intune will require Android 8.x or later. However, for Microsoft Teams Android devices, support will continue so this requirement does not apply. And then for Intune app protection policies and app configuration delivered via Managed devices app configuration policies, the requirement is for Android 9.0 or higher.)Android 8.0 and later (including Samsung KNOX Standard 3.0 and higher: requirements)   Android enterprise: requirements   Android open source project devices (AOSP) supported devices RealWear devices (Firmware 11.2 or later)HTC Vive Focus 3
Linux (It’s to be noted that Ubuntu Desktop already has a GNOME graphical desktop environment installed)Ubuntu Desktop 22.04.1 LTS with a GNOME graphical desktop environment.   Ubuntu Desktop 20.04 LTS with a GNOME graphical desktop environment.
Microsoft (Microsoft Endpoint Manager can still be used for the management of devices running Windows 11 the same as with Windows 10. Unless explicitly stated otherwise, assume that feature support that only mentions Windows 10 also extends to Windows 11. In addition, you should also note that configuring the available operating system features through MDM is not something that is supported by all Windows editions.)Windows 10/11 (Home, S, Pro, Education, Enterprise, and IoT Enterprise editions) Windows 10/11 Cloud PCs on Windows 365 Windows 10 LTSC 2019/2021 (Enterprise and IoT Enterprise editions) Windows 10 version 1709 (RS3) and later, Windows 8.1 RT, PCs running Windows 8.1 (Sustaining mode) Windows Holographic for Business Surface Hub Windows 10 Teams (Surface Hub)
Microsoft Intune-supported web browsersMicrosoft Edge (latest version)   Safari (latest version, Mac only)   Chrome (latest version)   Firefox (latest version)

Devices

By using Microsoft Intune, organizations can manage mobile devices more efficiently in a way that can enhance the security of organizational data. This means that the risk of malicious activity is reduced. And users can thus work from a greater number of locations. One of the greatest benefits of device management solutions such as these is that they can be both cost-efficient and convenient. This is because they support a wide variety of device types and platforms.

As a result of this, organizations are less likely to need to invest in new devices. And users can utilize the personal devices they already own in BYOD scenarios. With all this, however, it’s even more important for you to come up with a comprehensive template detailing what device types, OS platforms, and versions you will allow to have access to your organization’s resources.

Device ownership

As already mentioned, Microsoft Intune offers support for a wide variety of devices. And these devices can either be personal or organization-owned. When devices are enrolled via a device enrollment manager or a device enrollment program, they fall under the category of organization-owned devices. So, for instance, all devices that you enroll using the Apple Device Enrollment Program will categorize as organizational devices. Subsequently they will add to the device group, which will receive organizational policies and applications.

Bulk enrollment

As an organization, when enrolling a large number of devices into Intune, the process is simplified by the availability of a bulk enrollment feature. This feature provides you with a quick and easy way of setting up a large number of devices for management. A few use case examples. These include setting up devices for large organizations, setting up school computers, and setting up industrial machinery, among others. Intune has different ways to process the bulk enrollment of devices so you’ll need to determine which method fits best with your Intune design plan.

Design requirements and Microsoft Intune

When making the design considerations, there are specific requirements you’ll need to look at for the Intune environment that you want to establish. There may be instances that require you to make adjustments to the general advice that you get concerning Intune deployment.

It’s essential to ensure that certain capabilities will meet the requirements for the use cases needed for your organization. These features include configuration policies, compliance policies, conditional access, terms and conditions policies, resource profiles, and apps.

Microsoft Intune Configuration policies

You can use configuration policies for the management of the security settings on devices in Intune in addition to the features, as well. It’s important that you design configuration policies that follow the configuration requirements by Intune devices. And the necessary information to design your configuration policies in this manner are in the use case requirements section. This enables you to note the settings and their configurations. Not only that, but you’ll need to make sure to verify to which users or device groups to apply certain configuration policies. The various device platforms that you use will need to have at least one configuration policy assigned to them or even several whenever the situation calls for it.

Compliance policies and Microsoft Intune

These types of policies are responsible for establishing whether devices are complying with the necessary requirements. Therefore, determining whether or not a device is compliant becomes a significantly easier matter for Intune. And this is very important because it allows for devices to categorize as either compliant or non-compliant. And that status can then determine which devices are given access to the organization’s network and which ones to restrict.

Furthermore, if you intend on using Conditional Access, then it will probably be in your best interests to create a device compliance policy. Before you can decide on your device compliance policies, you may again want to refer to the use cases and requirements section. This will provide you with the necessary information concerning the number of device compliance policies you’ll require. It will also help you decide which user groups you’ll be applying them. Lastly, you need to have clearly defined rules. These will detail how long devices are allowed to remain offline before they move to the non-compliant list.

Conditional Access for Microsoft Intune

Conditional access plays the role of enforcer for your organization’s policies on all devices. That means that if any device fails to comply with your requirements, conditional access measures can implement. They will prevent them from accessing organizational resources such as email. When it comes to Intune, you’ll also benefit from its integration with Enterprise Mobility + Security. This will give your organization better protocols to control access to organizational resources. So, when it comes to your design plan you still need to look at Conditional Access. You’ll also decide whether or not you need it and what you’d want to secure with it.

Terms and conditions

Terms and conditions are essential for determining your organization’s requirements for any users that want access to the network. This is especially important in BYOD scenarios where some users may not be willing to meet those conditions. So, by establishing terms and conditions, your organization can give users an ultimatum if they want to access the organization’s resources. With Intune, you also get the option to add and deploy several terms and conditions to your user groups.

Profiles

Profiles play a key role by enabling the end user to connect to company data. To cater to the multiple scenarios that your organization may encounter, Intune provides several types of profiles. The information that you need, concerning the timeline for the configuration of the profiles, is obtainable by going through the section on use cases and requirements. Planning is easier because you’ll find all the device profiles grouped according to platform type. Profile types that you need to know about include email profiles, certificate profiles, VPN profiles, and Wi-Fi profiles.

Email profile

Email profiles are responsible for several capabilities. These include reducing the workload of support staff and enabling end-users with access to company email on their personal devices. Email clients will automatically set up with connection information and email configuration. Moreover, all this can be done without users having to perform any setup tasks. So this will ultimately improve consistency. However, not all of these email profiles will have support, on all devices.

Certificate profiles

Certificate profiles are the elements that enable Microsoft Intune to provide certificates to users or devices. The certificates that Intune supports include Trusted Root Certificate, PFX certificate, and Simple Certificate Enrollment Protocol (SCEP). For SCEP, all users who will receive it are going to need a trusted root certificate. This is because the latter is a requirement for SCEP certificate profiles. So, before you proceed make sure to have a clear idea of the SCEP certificate templates that you’d like to use. Your design plan should include a record of the user groups that require certificates. It should also include the number of certificate profiles needed, and to which user groups they’ll be targeted.

VPN profiles

Virtual private networks enable internet users to have secure access from almost any location across the globe. And using VPN profiles achieves the same thing for your organization’s users. They will be able to have secure access to the organization’s networks even from remote locations. Furthermore, Intune widens the options available to you by supporting VPN profiles from native mobile VPN connections and third-party vendors.

WiFi profiles

Wi-Fi profiles are important tools that enable your mobile devices to automatically connect to wireless networks. Using Intune, you can deploy Wi-Fi profiles to the various supported platforms. The device platforms that Wi-Fi profiles support include Android 5 and newer, Android Enterprise and kiosk, Android (AOSP), iOS 11.0 and newer, iPadOS 13.0 and newer, macOS X 10.12 and newer, Windows 11, Windows 10, and Windows Holographic for Business.

Microsoft Intune Apps

When using Intune, you’ll have the option to deliver apps to users or devices using any number of different ways. The apps that you can deliver cover a wide range including apps from public app stores, managed iOS apps, software installer apps, as well as external links. Moreover, this capability extends beyond individual app deployments. You’ll also be able to manage and deploy volume-purchased apps that you may have obtained from volume-purchase programs for both Windows and iOS.

App type requirements

Your design plan needs to include clear details regarding the types of apps that you will allow Intune to manage. This is especially necessary when you consider how apps deploy to users and devices. Information that you should consider for your criteria includes whether or not these apps will require integration with cloud services as well as the deployment measures you’d like to use.

You also need to decide if you’ll be availing these apps to employees using their personal devices and if users will need to have internet access to use the apps. Additionally, you need to verify if your organization’s partners will require you to provide them with Software-As-A-Service (SaaS) app data. Lastly, you need to check the availability of these apps to see if they will be available publicly in app stores or if they will be uniquely custom line-of-business apps.

App protection policies

These policies intend to safeguard your organization’s data by keeping it secure or contained in a managed app. Generally, these policies are rules that go into play when users try to access or move your organization’s data. These rules may also be enforced if users try to engage in actions that are prohibited or monitored when users are inside the app.

Therefore, you can reduce the risk of data loss because of how apps are set up to manage organizational data. Any app that can function with mobile app management will receive app protection policy support from Intune. It will be up to the organization and the team of admins to determine what restrictions you’d like to place on your organization’s data within certain apps.

Setting up Microsoft Intune

When you have your design plan in place, then you can begin looking at setting up Microsoft Intune for your environment. To do that, there will be a few things that you need to consider.

Requirements for Microsoft Intune

The first thing you need to have is an Intune subscription and the license for this is offered as a stand-alone Azure service. It is a part of Enterprise Mobility + Security (EMS) and is included with Microsoft 365. From your design plan, you’ll have a better idea of what the goals of your organization are and you may end up choosing Microsoft 365 because it comes with all of Microsoft Intune, EMS, and Office 365 apps.

Current status

If your organization doesn’t have any MDM or MAM solutions that it is currently using then Intune is probably the best choice for you. Especially if a cloud solution is what you want and then you’ll also benefit from features like Windows Update, configuration, compliance, and app features in Intune.

You can add Endpoint Manager admin center as well to the list of benefits that will be availed to you. Something that does need to be mentioned is that organizations that use more than one device management solution should consider using only a single one.

And if you’ve been using MDM providers such as MobileIron, Workspace ONE, and MaaS360 you’ll still have the option to move to Intune. This will come with a significant inconvenience, however, because before users can enroll their devices in Intune, they will have to unenroll their devices from the current management platform.

Before you make the move to Intune, you’ll need to note in your design plan all the tasks you’ve been running and the features you need so that you know how to proceed with setting up Intune. Unenrolling devices from your current MDM solution not only presents a challenge but makes devices temporarily vulnerable.

This is because while they are in that unenrolled state, they stop receiving all your policies thus security is compromised. By using conditional access, you can block unenrolled devices until they complete their enrollment in Intune.

You should plan to implement your deployment in phases that start with small pilot groups so that you can monitor the success of your approach. If all goes well you can then proceed with a full-scale deployment. Furthermore, those who currently use Configuration Manager and would like to move to Intune can use the options below:

Add tenant attach

This option offers you the simplest way to integrate Intune with your on-prem Configuration Manager setup. By leveraging this option, you can upload your Configuration Manager devices to your organization in Intune. And then once your devices are attached, you’ll be able to use Microsoft Endpoint Manager admin center to run remote actions including user policy and sync machine.

Set up co-management

With this option, Intune will be used for some workloads and Configuration Manager for others. You need to first navigate to Configuration Manager and then set up co-management. And then you proceed to deploy Intune and that also includes setting the MDM Authority to Intune. Once all this is done, devices will now be ready to be enrolled and receive the necessary policies.

Moving to Microsoft Intune from Configuration Manager

This may not happen often because Configuration Manger users tend to want to stay on this platform. However, making the move is possible if you decide that a 100% cloud solution is what you are looking for. You’ll need to first register existing on-prem Active Directory Windows client devices as devices in Azure AD. Then, you proceed to move your existing on-prem Configuration Manager workloads to Intune. Using this method would be good for providing you with a more seamless experience for existing Windows client devices but the downside is that it will be more labor-intensive for your admins.

And if we’re looking at new Windows client devices then you would be better off starting from scratch with Microsoft 365 and Intune:

  • Start by setting up hybrid Active Directory and Azure AD for the devices. Devices that are Hybrid Azure AD joined will be joined to your on-prem Active Directory as well as registered with your Azure AD. Having devices in Intune helps to safeguard your organization from malicious activity because these devices can receive your Intune-created policies and profiles.
  • Go to Configuration Manager and set up co-management.
  • Next, you need to deploy Intune and that includes setting the MDM Authority to Intune.
  • You’ll also need shift all workloads from Configuration Manager to Intune in the Configuration Manager section.
  • With all this done, you can go ahead and uninstall the Configuration Manager client on the concerned devices. This is something that can be done by creating an Intune app configuration policy that can perform the uninstallation once Intune has been set up.

Start from scratch with Microsoft 365 and Microsoft Intune

You can only use this approach for Windows client devices, so for those Windows Server OSs, Configuration Manager will be the option you have.

  • Deploy Microsoft 365, including creating users and groups.
  • Next, you need to deploy Intune and that includes setting the MDM Authority to Intune.
  • The Configuration Manager client will need to be uninstalled on all existing devices.

Microsoft Intune Deployment

The steps to follow for your Microsoft Intune deployment are given below:

  • Navigate to Endpoint Manager admin center and sign up for Intune.
  • Set Intune Standalone as the MDM authority.
  • Next, you need to add your domain account because if you don’t your-domain.onmicrosoft.com is what will be used as the domain.
  • Add users and groups that will receive the policies you create in Intune.
  • Users will then need to be assigned licenses and once that is done, devices can enroll in Intune.
  • The default setting allows all device platforms to enroll in Intune so if there are platforms that you’d like to block you’ll need to create a restriction.
  • You need to customize the Company Portal app so that it has your company details.
  • Come up with your administrative team and assign roles as necessary.

Windows 365 management and Microsoft Intune

Microsoft Intune not only manages your physical devices but will also play a key role in the management of your Windows 365 Cloud PCs. All you need to sign in is to head over to the Microsoft Intune admin center. This is where you’ll find the landing page for managing your Cloud PCs which is known as the Overview tab. Once signed in, go to Devices > Windows 365 (under Provisioning). In this section, you get a quick overview of the state of your Cloud PCs including the Provisioning status which summarizes the state of Cloud PCs in your organization, and the Connection health which summarizes the health of the Azure network connection in your organization.

All Cloud PCs page

On this page, you’re going to find a summary as well as a list view that will give you all the necessary information you need to know about the status of all the Cloud PCs in your organization. To make the task easier for you, the list view is refreshed every five minutes and allows you to search, filter, and sort. Additionally, there will be multiple Cloud PCs given to those users that have been assigned multiple Windows 365 SKUs. And what this means is that in the All Cloud PCs list view you will see multiple rows dedicated to a single user.

Column details

NameA combination of the assigned provisioning policy and the assigned user’s name will provide the name of the Cloud PC.
Device nameWindows computer name.
ImageSame image used during provisioning.
PC typeThe user’s assigned Windows 365 SKU.
StatusProvisioned: provisioning successful and user can sign in. Provisioning: still in progress. Provisioned with warning: warning is flagged in case of failure of a non-critical step in the provisioning process. Not provisioned: user has been assigned a Windows 365 license but not a provisioning policy. Deprovisioning: Cloud PC going through active deprovisioning. Failed: provisioning failed. In grace period: users with current Cloud PCs are placed in this state when a license/assignment change occurs for them. Pending: this happens when a provisioning request cannot be processed because of a lack of available licenses.
SUserUser assigned to the Cloud PC.
Date modifiedTime when last change of state of the Cloud PC occurred.
Third-party connectorWhen you have third-party connectors installed and currently in use on Cloud PCs, the connector provider is displayed as well as the connector status.

Remote management

Your organization can take advantage of the Microsoft 365 admin center to remotely manage your Windows 365 Business Cloud PCs. There will be several remote actions available to you but to access them you need Azure AD role-based access roles, either Global administrator or Windows 365 administrator. Once you have one of those two roles assigned, you’ll have several methods you can use for Cloud PC management including:

  • Windows365.microsoft.com
  • Microsoft 365 admin center
  • Microsoft Intune (on condition that you have all the necessary licenses)
  • Microsoft Graph

Cloud PC management design options

When it comes to the design options for Cloud PC management, there will be three options that we are going to look at:

Option 1 (Windows 365 Azure AD Joined + hosted in Microsoft Network)

Microsoft Intune

  • Cloud PCs are hosted in the cloud (Microsoft Hosted Network) and managed in the cloud (Intune)
  • Cloud PCs are enrolled as Azure AD joined and managed out-of-the-box by Intune
  • Eliminates customer constraints
  • Cloud PCs will get a unified endpoint management integration from the Microsoft Endpoint Manager admin portal
  • Simplifies Cloud PC management workloads such as app delivery and endpoint security among others
  • Comfortably address Cloud PC remote management needs

Co-Management

  • This is optional and allows you to bring your on-premises device management solution MECM for Option 1
  • Requires MECM + Cloud Management Gateway
  • Depends on customer device management on-premises environment
  • Some considerations before managing Cloud PCs include: Azure subscription and on-premises infrastructure, deployment and configuration of a CMG as well as a public SSL certificate for this CMG, enable Co-Management in Configuration Manager, and more.

Option 2 (Windows 365 Azure AD Joined + hosted in Customer Network)

Microsoft Intune:

  • Cloud PCs are hosted in the Customer Network and managed in the cloud
  • Cloud PCs are enrolled as Azure AD joined and managed out-of-the-box by Intune
  • Eliminates customer constraints
  • Cloud PCs will get a unified endpoint management integration from the Microsoft Endpoint Manager admin portal
  • Simplifies Cloud PC management workloads such as app delivery and endpoint security among others
  • Comfortably address Cloud PC remote management needs

Co-Management

  • This is optional and allows you to bring your on-premises device management solution MECM for Option 2
  • Requires MECM. Cloud Management Gateway is optional
  • Depends on customer device management on-premises environment
  • Some considerations before managing Cloud PCs include: on-premises infrastructure, configuration of Intune to deploy the CM client for your Cloud PCs, enable Co-Management in Configuration Manager.

Option 3 (Windows 365 Hybrid Azure AD Joined + hosted in Customer Network)

Co-management:

  • Cloud PCs are hosted in the Customer Network and managed by the customer (Co-Management)
  • Cloud PCs are enrolled as Hybrid Azure AD joined and managed by Co-Management
  • Requires MECM
  • Depends on customer device management on-premises environment
  • Cloud PCs will get a unified endpoint management integration from the Microsoft Endpoint Manager admin portal
  • Simplifies Cloud PC management workloads such as app delivery and endpoint security among others
  • Comfortably address Cloud PC remote management needs
  • Some considerations before managing Cloud PCs include: on-premises infrastructure, configuration of MECM to deploy the CM client for your Cloud PCs, enable Co-Management in Configuration Manager.

Microsoft Intune

  • This is optional and if you don’t have a MECM environment you can use Intune as your Cloud PC device management solution for Option 3
  • Some considerations for this option include: configuration of Azure AD Connect for Hybrid Domain Joined, Hybrid Azure AD Joined Cloud PCs need to be directly attached to an on-premises AD environment, for device management the Active Directory environment will depend on Group Policy Objects.

Wrap Up About Microsoft Intune

Device and application management can prove to be a very challenging task to get right for a lot of organizations. Finding the right solution that can streamline application use across your organization’s devices without breaking the bank would be a dream for any organization. You also want a platform that can increase the productivity levels of your IT staff by minimizing the complexity of device management and by extension reducing the time spent on device management.

With Microsoft Intune, you can get this and plenty more. This MDM and MAM solution will enhance the security of your organization by establishing strict access protocols for your organization’s resources. This means greater protection at a time when endpoints are increasingly a vulnerable point for malicious attacks. Intune can provide you with peace of mind while providing an effective management platform that can vastly improve the way your organization operates.

Microsoft Intune – New Updates in PowerShell Scripts

Microsoft Intune is one of those brilliant products that has helped to optimize IT infrastructure for many businesses. It’s a platform that can transform your business into a modern workplace. And its capabilities are almost without limit. If you want to upload PowerShell scripts in Intune, there is the Microsoft Intune management extension (IME) that you can use for that. This management extension can enhance Mobile Device Management (MDM) resulting in a simpler move to modern management. With all this done, you can then run these scripts on Windows 10 devices. PowerShell scripts are important in a lot of different use cases and this blog is going to take a look at what this technology can do.

What is PowerShell?

PowerShell is a scripting and automation platform belonging to Microsoft. It’s an amazing product that is both a scripting language as well as an interactive command environment that is built on the .NET framework. Released back in 2006, PowerShell was basically a replacement for Command Prompt as the default method for automation of batch processes and creation of customized system management tools. PowerShell can easily automate laborious admin tasks by combining commands known as cmdlets and creating scripts. Available in all Windows OS starting with Windows 2008R2, PowerShell plays a huge role in helping IT professionals configure systems.

Adopting modern management

Modern workplaces now have plenty of user and business-owned platforms allowing users to work from anywhere. With MDM services like Microsoft Intune, you can manage devices that are running Windows 10. The Windows 10 management client will communicate with Intune to run enterprise management tasks. Windows 10 MDM features will be supplemented by IME. With this in place, you can create PowerShell scripts to run on Windows 10 devices e.g, creating a PowerShell script that does advanced device configurations. Having done this, you can upload the script to Intune and assign the script to an Azure AD group. Then run the script. Moreover, you can monitor the run status of the script from start to finish.

Latest updates from Microsoft

In November 2020, Microsoft announced the general availability of PowerShell 7.1 which is built on the foundation of PowerShell 7.0. The goal was to bring about improvements and fixes to the existing technology. Some of these features, updates, and breaking changes include:

  • PSReadLine 2.1.0, including Predictive IntelliSense
  • PowerShell 7.1 has been published to the Microsoft Store
  • Installer packages have been updated for new operating system versions with support for ARM64
  • 4 new experimental features and 2 experimental features promoted to mainstream
  • A number of breaking changes that improve usability

Using scripts in Intune

Before IME can automatically install, when a PowerShell script or a Win32 app is assigned to the device or user, a few prerequisites should be met:

  • Windows 10 version 1607 or later, Windows 10 version 1709 or later for devices enrolled using bulk auto-enrollment.
  • Devices joined to Azure AD including Hybrid Azure AD-joined which consists of devices that are joined to Azure AD, and are also joined to on-premises Active Directory (AD).
  • Devices enrolled in Intune namely devices enrolled in a group policy, devices that are manually enrolled in Intune, and co-managed devices that use both Configuration Manager and Intune.

Script policy creation

Start by signing in to the Microsoft Endpoint Manager admin center. From there you’ll select Devices then PowerShell scripts then add. Under Basics, you will then have to provide a name and a description for the PowerShell script. Next, you go to Script settings and you’ll have to enter the required properties. After that, you select Scope tags, however, these are optional. And then select Assignments > Select groups to include and an existing list of Azure AD groups will be shown. Lastly, in Review + add, you’ll see a summary of the settings you configured. Select Add to save the script. When you have done so, the policy is deployed to the groups you chose.

Important considerations

If you have scripts that are set to user context with the end-user having admin rights, by default, the PowerShell script runs under the administrator privilege. Also, end-users don’t need to sign in to the device to execute PowerShell scripts. The IME agent checks with Intune once per hour and after every reboot for any new scripts or changes. In the event of a script failing, the agent attempts to retry the script three times for the next 3 consecutive IME agent check-ins. And as far as shared devices are concerned, the PowerShell script runs for every new user that signs in.

PowerShell scripts limitations

Although with Microsoft Intune you can deploy PowerShell scripts to Windows 10 devices, there are a few limitations worth noting. These include:

  • You won’t get support for running PowerShell scripts on a scheduled basis.
  • Although you can see whether the PowerShell script execution succeeded or failed, the output generated is only available on the endpoint that executes it and is not returned to the MEM Admin Portal.
  • Since executed PowerShell scripts are visible in the Intune Management Extension log file as plain text, credentials can’t be passed securely.
  • The Intune Management Extension agent responsible for executing PowerShell scripts on the endpoints only checks once an hour for new scripts so there is a delay with execution.

Wrap up about Microsoft Intune

Maximizing the time we have is increasingly a massive concern for most organizations. Technological innovation has made it such that we can have more productive time on our hands. PowerShell is a product that is very useful to IT professionals for overall system management. By being able to automate the administration of Windows OS and other applications, organizations can operate more efficiently. The evolution of this platform since its release fourteen years ago has seen it grow from strength to strength. Undoubtedly, this is a product that can easily boost your productivity.
